Handling line endings

Line endings can be extremely annoying when sharing code between mac / linux / windows.

Each operating system handles line endings differently, with the two main 'end of line' (EOL) types being:

• CRLF (windows)
• LF (unix / mac)

What are line endings?

A hangover of ASCII code being developed in the 1960s, CRLF actually represents two instructions, 'carriage return' (CR) and 'line feed' (LF).

If we imagine a typewriter, CR instructs the 'carriage' (the part which horizontally positions the paper) to return to its starting position, then LF feeds paper into the carriage, creating a newline.

The codes behind line endings

Imagine we access a windows machine and create a text file with the following content:

a

b

c

If we were to look at the ASCII behind the file, it'd look something like:

61 0D 0A 0D 0A 62 0D 0A 0D 0A 63

note - I chose hex because it's a bit more compact than the raw binary

However if we had created our text file on a mac, it might instead look like:

61 0A 0A 62 0A 0A 63

Here's what each hex represents:

• 61 - a
• 62 - b
• 63 - c
• 0D - CR
• 0A - LF

Notice that wherever there is a line break, windows includes 0D 0A (CR LF) whereas mac includes only 0A (LF).

Reading & writing text files with different line endings might have led to issues in the past, but nowadays most programs / operating systems handle it gracefully, so users don't have to worry about which EOL style was used.

It's usually when we involve source control that the problems start to appear.

A real-life scenario

Let's run through a scenario (with a link to where this happened to me 😅):

1. We fork a repository to fix a bug that has been reported
2. Our first commit goes in, where we edited a few lines in one file
3. We continue making changes, eventually we've made changes in 3 different files
4. We submit the PR, and notice the diff is unreadable!

Git is showing us that every single line in the file has changed, but it isn't highlighting a specific area! It turns out that we've accidentally changed all the line endings in each file we edited.

In our scenario:

• The repository didn't include a .gitattributes file
• The repository used CRLF line endings (this was surprising)
• I was working on macOS with core.autocrlf set to "input" globally

gitattributes

The .gitattributes file handles a few different things, but the most common use is to tell git how to handle line endings for different filetypes.

They range in complexity, from a simple:

# Handle line endings automatically
# for files detected as text
# and leave all files detected
# as binary untouched.
* text=auto

To something more bespoke:

# Set the default behavior,
# in case people don't have
# core.autocrlf set.
* text=auto

# Explicitly declare text files you
# want to always be converted
# to native line endings on checkout.
*.c text
*.h text

# Declare files that will always
# have CRLF line endings on checkout.
*.sln text eol=crlf

# Denote all files that are truly
# binary and should not be modified.
*.png binary
*.jpg binary

The flags above show:

• binary - don't process this file for line endings
• text - process this file for line endings
• eol - convert all line endings to this style

core.autocrlf

The core.autocrlf setting controls how git handles line endings on checkout and on commit.

There are three options that can be used:

• true
• input
• false

The true option will convert the line endings to CRLF when checked out, but ensure line endings are LF on commit.

The input option won't change line endings on checkout, but will ensure that files are LF on commit.

The false option will disable any conversion, allowing CRLF line endings to be committed.

It's worth noting that these 'generic' options are overridden by the .gitattributes file, which is why it's usually a good idea to include one of these files if you're working on a project with developers who use a mixture of operating systems.

What's the best configuration?

Generally git reccomends text files use LF line endings when committed to source control. Because of this, the best 'default' option for core.autocrlf varies depending on the OS:

• Windows reccomends true, which gives you CRLF locally, but LF in source control
• Unix / MacOS reccomends input, which ensures that code is LF when checked in, but doesn't convert on checkout

How can we set the config?

It's often useful to setup a global git configuration, so that we have some reasonable defaults when working in new repositories.

Then when a repository needs bespoke settings, we can set a local config which will only be used for that particular repo.

Here are some examples:

Check the current global git config

git config --global --list

Set the global autocrlf config to input

git config --global core.autocrlf input

Check the autocrlf config which will be used for the current repo

git config --get core.autocrlf

Set the local repo config to false

git config --local core.autocrlf false

Summary

I hope you've found something useful in this article; most of this information has come from me having to deal with line endings issues, but the ASCII information I read in Charles Petzold's excellent book CODE.

The general best practice to line endings would be:

1. Set up a gitattributes file in all shared repositories
2. Set autocrlf globally to the git reccomendation
3. If a repo uses CRLF exclusively, locally set your autocrlf value to false

Extra!

Recently I've seen that Prettier includes an end-of-line config option. This might be a nice way to help reduce the amount of erroneous line endings that get included in shared projects, so is probably worth setting if using prettier on a project.

This prettier option is also useful if you need to change the line-endings for a particular file; set it to what you need, and format the file!

Thanks for reading 🥳
